    Stable Water Bottling Equipment / Automatic Liquid Bottle Filling Machine

    Ask Lasest Price
    Brand Name : StepChina/Mingstar
    Model Number : CGF16-16-5
    Certification : CE
    Price : negotiation
    Supply Ability : 30 sets per year
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Stable Water Bottling Equipment / Automatic Liquid Bottle Filling Machine

    Automatic Bottle Filling Machine 16 Pieces Heads 7000BPH for 500ml CGF16-16-5


    Description:

    1. this machine uses direct connection technology between air conveyor and in-feeding starwheel to substitute in-feeding screw and conveyor to ease the process of bottle-size-changing.
    2. Neck-hanging technology is applied in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily, without equipment height adjustment, only arch board and starwheel such little nylon parts need to be changed.
    3. Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.
    4. Rapid gravity filling valve with high flow makes filling faster with accurate liquid level and without any liquid loss.
    5. splint of starwheel using twist descending way to simplify the process of bottle-size-changing.
    6. The machine applies to the production of natural mineral water, purified water and mineralized water

    Quick Detail:


    Name

    Water filling machine, water bottling machine, water filler, water filling equipment

    Brand Name


    StepChina


    Capacity



    7000B/H for 500ml


    Bottle size


    from 200ml to 2500ml


    Function


    Bottle washing, water filling, bottle capping

    Usage


    Bottled water production


    Operation



    Touch screen


    Control system


    PLC automatic control


    Stable Water Bottling Equipment / Automatic Liquid Bottle Filling Machine


    Suitable bottle:

    • kinds of PET bottle, size from 200ml to 2500ml;
    • bottle cap: screw cap

    Stable Water Bottling Equipment / Automatic Liquid Bottle Filling Machine


    Specifications:



    Name



    Rinsing, filling and capping machine


    Model



    CGF 16-16-5


    Material



    Stainless steel 304


    Production capacity



    7000B/H (500ml)


    Detail specification



    Number of rinsing heads



    16


    Number of filling heads



    16


    Number of capping heads



    5


    Applicable bottles



    PET bottle,plastic bottle


    Bottle diameter



    Φ55-110mm


    Bottle Height



    186-310mm


    Bottle Volume



    200-2500 ml


    Applicable caps



    Plastic screw cap


    Total power



    2.2 Kw


    Weight



    3000 Kg



    working process:


    Empty bottle------air convyeor------CGF16-16-5-------lamp inspector------labeling machine------inkjet printer------packing machine------palletizer


    Applications:


    1. Bottled mineral water production.

    2. Bottled purified water production.


    2.2KW Bottled Water Filling Machine 16 Pieces Heads 7000BPH for 500ml



    FAQ:


    1) Can your factory provide the whole plant from A to Z?
    A: Yes, we can provide the complete plant, from bottle blowing machine, water purification plant, to filling packing plant.

    2) Are all machinery your factory made?
    A: Our factory make the water purification and filling packing plants. We do not make the bottle blowing machinery,
    we have good quality bottle blowing machinery partner, and we provide to customer same long warranty time and good after service.
    We shall connect the whole production line for test running before shipment.


    3) How can I know the machinery quality before I order?
    A: Frist, we will invite you visiting our factory to check the quality, and introduce our technology advantages. You will be easy to compare ours equipment with others.


    4) What certificates you can provide?
    A: Our factory provide the CE, SGS, ISO, and accroding to some countries, we also can provide the Pvoc, Coc, Soncap...ect


    5) Can your factory make the bottle drawing, workshop layout, and labels for us?
    A: We can help customers design their own bottle shape, workshop layout and label drawings, these jobs are free charge.
    (Workshop layout is based on land size of client)


    6) Installation and Training Time
    A: We have professional engineer for oversea installaion and training, they have much experience over 10 years working in this industry. Clients need to pay round air ticket, visa charge, accommodation and 100 USD/day. (PS: 100 USD/day is personal charge for engineer, our company doesn’t take it.)



    Model list:


    Model

    Capacity

    CGF14-12-5

    5000BPH

    CGF16-16-5

    7000BPH

    CGF24-24-6

    12000BPH

    CGF32-32-8

    15000BPH

    CGF40-40-10

    18000BPH

    CGF50-50-12

    22000BPH

    CGF60-60-15

    25000BPH

    CGF72-72-18

    32000BPH
